Hantek DSO2D15 Digital Oscilloscope 150MHz with AFG Signal Generator for Diagnostics

Hantek DSO2D15 Digital Oscilloscope with Integrated AFG Signal Generator

✔ 150 MHz bandwidth for precise signal analysis
✔ 1 GSa/s sample rate for detailed measurement results
✔ Integrated 25 MHz AFG signal generator
✔ Extensive trigger and analysis functions
✔ Ideal for development, diagnostics, laboratory, and workshop

The Hantek DSO2D15 Digital Oscilloscope combines powerful measurement technology with an integrated arbitrary function generator in a compact device. With 150 MHz bandwidth, a sample rate of 1 GSa/s, and extensive analysis functions, the oscilloscope is suitable for professional applications in electronics development, vehicle diagnostics, research, and technical service areas.

The combination of signal analysis and signal generation allows electronic systems to be efficiently tested, fault sources located, and communication signals reliably evaluated.

Powerful Digital Oscilloscope for Precise Measurements

With its high bandwidth of 150 MHz, the Hantek DSO2D15 reliably captures even fast signal waveforms. The high sample rate enables a detailed representation of signal edges, clock signals, and transient events.

Especially with modern control units, embedded systems, or industrial electronics applications, precise signal display is crucial for early detection of errors and malfunctions.

Integrated AFG Signal Generator for Test Tasks

The integrated arbitrary function generator with an output frequency of up to 25 MHz significantly expands the range of applications. Various standard waveforms such as sine, square, triangle, and pulse waves can be generated directly.

Additionally, individual signal forms can be created to test electronic components under realistic conditions and efficiently support development processes.

Deep Memory for Extensive Signal Recording

The 8M memory depth allows for recording long signal waveforms with high detail accuracy. This is particularly helpful for sporadically occurring errors or rare signal events.

Even complex measurements can thus be comprehensively analyzed and documented.

Versatile Trigger and Analysis Functions

The Hantek DSO2D15 offers a total of 14 trigger modes for a wide range of measurement situations. This allows signal events to be specifically captured and stably displayed.

• Edge Trigger
• Pulse Trigger
• Video Trigger
• Window Trigger
• Pattern Trigger
• Interval Trigger
• Serial Protocol Trigger

The integrated analysis functions support users in the rapid evaluation of complex signals and communication processes.

Bus Decoding for Modern Communication Systems

The device supports the decoding of important communication protocols such as UART, I2C, SPI, CAN, and LIN. This allows data transmissions to be analyzed directly and communication errors identified more quickly.

Especially in the diagnosis of electronic controls and embedded systems, this function offers a significant practical advantage.

Automatic Measurement Functions for Efficient Work

With a total of 32 automatic measurement functions, important signal parameters can be evaluated immediately.

• Frequency
• Period
• RMS Value
• Peak Values
• Rise and Fall Times
• Duty Cycle

Additional real-time statistics for minimum, maximum, and average values support a quick assessment of signal quality.

Technical Data

Areas of Application for the Hantek DSO2D15

• Electronics Development
• Control Unit Diagnostics
• Embedded Systems
• Industrial Electronics
• Laboratory and Research
• Technical Training
• Service and Troubleshooting

Scope of Delivery

• Hantek DSO2D15 Digital Oscilloscope
• Instruction CD
• Battery Clamp Connection

Professional Measurement Technology for Development and Diagnostics

The Hantek DSO2D15 impresses with its combination of high measurement performance, integrated signal generator, and extensive analysis functions. The versatile application possibilities make the device a reliable solution for developers, service technicians, research institutions, and technical training areas.
